Ranger® 330MPX™ Engine Driven Welder (Kohler®)

The Ranger® 330MPX™ welder and generator leads the way for the construction, maintenance, and service truck industries. The modern design and advanced features allow this machine to streamline welding operations and improve efficiency at the job site. The Ranger 330MPX has a 20 percent smaller footprint and is 25 percent lighter than other machines in its class. It transports to the field with less bulk and less effort, leaving more room for other tools and accessories needed on your job site. The Ranger 330MPX’s digital user interface offers a suite of advanced technology that improves weld performance and productivity. Enhanced remote control capabilities offer operators the ability to select their preferred remote amperage scale along with fine tune adjustments available on hot start, arc force, and pinch controls. The Ranger 330MPX is up to 60% quieter than other machines in its class to enhance safety and comfort in the workplace.

Features:

• Ready.Set.Weld®: Intuitive push-and-turn digital controls make setup a breeze.
• Chopper Technology®: Provides easy starts, a smooth and consistent arc, and low spatter for optimal bead appearance.
• ArcFX™ Technology: Provides instant graphical feedback on how settings affect the weld outcome.
• CrossLinc™ Remote Technology: Communicates voltage control to the welding power source through one common weld cable.
• Clean AC generator with 10 kW of continuous, consistent power to keep tools running without interruption.
• Plenty of power at 330A/28V for 100% duty cycle to weld 1/4 in. 7018 electrode. Arc gouging capabilities up to 3/16 in. carbon electrode.
• The maintenance screens allows the machine to record engine hours for proper service and maintenance.
• Enable the supervisor and operator passcode protection to lock settings and weld modes.
• Engine Driven Weld Modes: downhill pipe, touch-start pulse TIG, and pulse spool gun.


What's Included:

• (1) Ranger 330MPX Engine Driven Welder


Application:

• Construction; Construction & Field Erection; General Fabrication; Structural Fabrication; Structural Welding

General Specification:

Engine Driven Welders Specification:
